YAGEO Automotive Multilayer Ceramic Capacitors (MLCCs)

YAGEO Automotive Multilayer Ceramic Capacitors (MLCCs) are AEC-Q200 qualified and reliable in a wide -55°C to +150°C temperature range. The MLCCs feature a 0.1pF to 10µF capacitance range, 6.3VDC to 1kVDC voltage rating range, and tolerances from 0.05pF to 0.5pF or 1% to 20%. The MLCCs are available in C0G (NP0), X5R, X6S, X7R, X8G, and X8R dielectrics in various case sizes ranging from 0201 to 1210. These automotive-grade Class I and Class II devices are suitable for all general-purpose, entertainment, comfort/security, and information applications.

Features

  • Class 1 and Class 2 devices
  • Surface mount
  • Standard or flexible (soft) termination options
  • Dielectrics
    • C0G (NP0)
    • X5R
    • X6S
    • X7R
    • X8G
    • X8R
  • 0201 to 1210 case size range
  • 0.1pF to 10µF capacitance range
  • 6.3VDC to 2kVDC voltage rating range
  • Tolerance ranges
    • 0.05pF to 0.5pF
    • 1% to 20%
  • -55°C to +150°C operating temperature range
  • 0.3mm to 2.5mm height range
  • 0.3mm to 3.2mm width range
  • AEC-Q200 qualified

Applications

  • General-purpose
  • Entertainment
  • Comfort/security
  • Information

Infographic

YAGEO Automotive Multilayer Ceramic Capacitors (MLCCs)

View Full Infographic
