Vishay Semiconductors Rectifiers & TVS in DFN 3820A Package

Vishay Semiconductors Rectifiers and TVS in DFN 3820A Package feature a 0.88mm typical height and low forward voltage drop with AEC-Q101 qualification. These rectifiers cover a 1A to 5A forward current range with 200V, 400, or 600V repetitive peak reverse voltage options. The DFN-packaged components are ideal for automatic placement in automotive, industrial, and commercial applications.

Features

Wettable flanks allow easy inspection with AOI (automated optical inspection), no X-ray necessary
DFN3820A package, 3.8mm x 2.0mm
Very low profile, typical height of 0.88mm
1A to 5A forward current range
200V, 400, or 600V repetitive peak reverse voltage options
5pF to 24pF typical junction capacitance range
Ideal for automated placement
Low forward voltage drop
Single circuit configuration
-55°C to +175°C operating temperature range
Molding compound meets UL 94V-0 flammability rating
Meets MSL level 1, per J-STD-020, LF maximum peak of +260°C

AEC-Q101 qualified
Lead-free, halogen-free, and RoHS compliant
Standard SEx0Nx components
- Oxide planar chip junction
- Typical IR less than 0.1 μA
- ESD capability
- Compatible with SMP (DO-220AA) package case outline
Ultrafast VS-xEAH02HM3 components
- Low power losses and leakage current
- For PFC, CRM snubber operation

Applications

Ultrafast VS-xEAH02HM3 components
- High-frequency inverters
- DC/DC converters
- Freewheeling diodes
- Clamping and snubber
- Polarity protection
- Dual voltage injector drivers
- Piezo drivers
- ECU
- Antilock braking systems (ABS)
- HID and LED lighting

Standard SEx0Nx components
- General-purpose
- Power line polarity protection
- Rail-to-rail protection
