Vishay / Roederstein THB DC-Link Metallized Polypropylene Film Caps

Vishay Roederstein THB DC-Link Metallized Polypropylene Film Capacitors are AEC-Q200 qualified, automotive-grade DC-Link capacitors featuring high robustness under high humidity. These fixed, radial type capacitors offer a capacitance range of 1µF to 80µF within a voltage range of 500V to 1200V. The MKP1848H DC-Link capacitors are ideal for out-of-doors applications or in other harsh environments.

Features

High robustness under high humidity
High ripple current capability
Radial type, THB +85°C, 85% RH, 1000h at rated U_NDC
Low ESR

Low ESL
AEC-Q2200 qualified
Lead-free
Halogen-free
RoHS compliant

Applications

Outdoor applications
Harsh environments
Renewable energy inverters

UPS
Battery chargers
Motor drives

Specifications

1µF to 80µF rated capacitance range
±5% or ±10% capacitance tolerances
04/085/56 climatic testing class
+85°C rated temperature
+105°C maximum permissible case temperature, observing voltage derating
0.2 x U_NDC Maximum applicable peak-to-peak ripple voltage
Polypropylene film dielectric
Metalized dielectric capacitor electrodes
Mono construction

Plastic case sealed with resin, flame retardant UL 94 V-0
Tinned wire terminals
<1nH self-inductance (L_S) per mm of lead spacing
Withstanding DC voltage between terminals – 1.5 U_NDC for 10s, cut off current of 10mA, rise time ≤1000V/s
Insulation resistance – RC between leads, after 1 minute >10,000s, measuring voltage of 500V
