Vishay / Polytech T50 vPolyTan™ Polymer Chip Capacitors

Vishay / Polytech T50 vPolyTan™ Polymer Chip Capacitors are designed for high temperature and high humidity applications. These devices feature a capacitance range of 10μF to 330μF with ±20% tolerance, voltage range of 2.5V_DC to 35V_DC, and ultra-low ESR. The series is ideal for use in a variety of applications, including decoupling, smoothing, filtering, switch mode, and point-of-load power supply. Vishay / Polytech T50 vPolyTan Polymer Chip Capacitors are AEC-Q200 qualified.

Features

-55°C to +125°C temperature range
High temperature and high humidity operations
Qualification testing based on AEC-Q200
Ultra-low ESR

7343-31 EIA size molded case
Ni / Pd / Au terminations
Level 3 moisture sensitivity

Applications

Automotive
- Infotainment
- Cockpit electronics
High-temperature industrial operations

Decoupling, smoothing, filtering
Switch-mode and point-of-load power supplies
Storage and networking infrastructure equipment

Vishay / Polytech T50 vPolyTan™ Polymer Chip Capacitors

Features

Applications

Infographic – 330μF, 6.3V

Infographic – 680μF, 4V
