Vishay / Dale RHA Pre-Charge & Discharge Wirewound Resistors

Vishay / Dale RHA Pre-Charge and Discharge Wirewound Resistors are AEC-Q200 qualified and offer a 7.5W to 50W power range and ±1% to ±5% tolerance. These resistors feature molded construction for total environmental protection, complete welded construction, and mount on a chassis to utilize the heat sink effect. Vishay RHA resistors provide excellent stability in operation and have a -55°C to +250°C temperature range.

Features

AEC-Q200 qualified
Molded construction for total protection
Complete welded construction

Mounts on chassis to utilize the heat-sink effect
Excellent stability in operation

Specifications

7.5W to 50W power range
0.1Ω to 39.2KΩ resistance range
±1%, ±3%, and ±5% tolerance

-55°C to +250°C operating temperature range
Meets requirements of ANSI J-STD-002 for solerability

Vishay / Dale RHA Pre-Charge & Discharge Wirewound Resistors

Features

Specifications

Dimensions

Infographic
