Vishay / Beyschlag MMU 0102 VG03 Thin Film Reliable MELF Resistors

Vishay / Beyschlag MMU 0102 VG03 Thin Film Reliable MELF Resistors are ideal for high-reliability applications typically found in aircraft, military, and spacecraft electronics. These resistors are IECQ-CECC approved to EN 140401-803 version E standards and feature advanced metal film technology. Vishay / Beyschlag MMU 0102 VG03 MELF Resistors offer a 0102 DIN size, 0.2W rated dissipation, 150V operating voltage rating, and 100Ω to 2.21MΩ resistance range. These resistors supplement the professional and precision MMU 0102 MELF resistor family.

Features

IECQ-CECC approved to EN 140401-803, version E
Established reliability, failure rate level E6

Advanced metal film technology
Single lot date code

Applications

Medical
Military
Aerospace

Specifications

0102 DIN size
RC2211M metric size code
8mm width
4mm pitch
100Ω to 2.21MΩ resistance range

±1%; ±0.1% resistance tolerance
±50ppm/K; ±15ppm/K temperature coefficient
0.2W rated dissipation
150V operating voltage
-55°C to +125°C operating temperature range
