Vishay / BC Components 193 PUR-SI Aluminum Electrolytic Capacitors

Vishay / BC Components 193 PUR-SI Snap-In Aluminum Electrolytic Capacitors (AECs) offer high ripple current and 5000 hours at +105°C useful life. Vishay / BC Components 193 PUR-SI Capacitors offer up to 500V rated voltage in a compact 22mm x 25mm to 35mm x 60mm case. The series is designed for use in solar photovoltaic (PV) inverters, smoothing and filtering, and motor controls / small drives.

Features

Compact design (22mm x 25mm to 35mm x 60mm nominal case size)
Improved ripple current
5000 hours at +105°C useful life
Up to 500V voltage range
47μF to 820μF rated capacitance range

±20% tolerance
Polarized aluminum electrolytic capacitors, non-solid electrolyte
Keyed polarity snap-in version available
High reliability

Applications

Solar photovoltaic (PV) inverters
Motor controls / small drives
Smoothing and filtering

Standard and switched-mode power supplies
Industrial air conditioning

Dimensions (mm) & Available Forms

Chart - Vishay / BC Components 193 PUR-SI Aluminum Electrolytic Capacitors
