TRACO Power TRV 1M 1W Medical DC/DC Converters

TRACO Power TRV 1M are 1W DC/DC converters in a compact SIP-9 package with reinforced isolation of 5000V_AC for medical and industrial applications. TRACO Power TRV 1M offers models with different input voltages (±10%) between 5V_DC and 24V_DC. With continuous short-circuit protection and low leakage current of less than 2μA, this converter series is ideal for protecting any connected interface or applied parts to patients. An operating temperature range from -40°C to +85°C without derating and certifications according to IEC/EN/ES60601-1 3rd edition for 2xMOPP and IEC/EN/UL62368-1 make this series suitable for a variety of applications in which a medical isolation system and short-circuit protection are needed.
