TRACO Power Medical DC/DC Converters

TRACO Power Medical DC/DC Converters are advanced solutions for optimally powered medical applications. These medical DC/DC converters offer high reliability with compact construction and certification according to IEC60101-1 3rd edition and EMC emission to IEC 60601-1-2 4th edition. These converters are designed specifically for medical equipment requiring certified compliance with highly regulated medical standards. The devices are designed according to ISO 14971, including the risk management file. TRACO Power Medical DC/DC Converters range from 1W to 60W output power, covering DC inputs from 4.5V to 72V, single or dual outputs, and a reinforced isolation system of 5000V_AC with a very low leakage current of <5µA for 2XMOPP compliance.

Features

IEC/EN/ES 60601-1 3rd Edition for 2 x MOPP
Risk Management ISO 14971
IPC-A-610 Class 3 High-Performance Acceptability

EMC Emission acc. to IEC 60601-1-2 ed. 4
Quality Management ISO 13485
5-year warranty

Specifications

Single or dual output
1W to 60W output power range
Input ranges covering 4.5V_DC to 72V_DC
Reinforced 5kV I/O isolation
Output voltage ranges from 3.3V_DC to 24V_DC

Industry-standard footprints
- SIP-9
- SMD (DIP-16), DIP-16, or DIP-24
- 1.6″ x 1″ or 2″ x 1″ quarter brick
