Texas Instruments SN74AHC86 Quadruple 2-Input Exclusive-OR Gates

Texas Instruments SN74AHC86 Quadruple 2-Input Exclusive-OR Gates are quadruple 2-input exclusive-OR gates. These devices perform the Boolean function Y = A ⊕ B or Y = AB + A B in positive logic. A common application is as a true or complement element. If one of the inputs is low, the other input is reproduced in true form at the output. If one of the Texas Instruments SN74AHC86 inputs is high, the signal on the other input is produced inverted at the output.

Features

Operating range of 2V to 5.5V V_CC
Latch-up performance exceeds 250mA per JESD 17
ESD protection exceeds JESD 22
- 2000V human-body model
- 200V machine model
- 1000V charged-device model

Applications

Detect phase differences in input signals
Create a selectable inverter or buffer

Texas Instruments SN74AHC86 Quadruple 2-Input Exclusive-OR Gates

Features

Applications

Functional Block Diagram
