Texas Instruments LV14360PEVM Evaluation Module

Texas Instruments LV14360PEVM Evaluation Module provides the requirements and interface options for evaluating the LV14360 60V, 3A Step-Down Regulator with 1µA shutdown current. The LV14360 Step-Down Regulators offer a wide input range from 4.3V to 60V. The Regulators are suitable for a wide range of applications, including automotive and industry, for power conditioning from unregulated sources.

The TI LV14360PEVM Evaluation Module is designed to provide the design engineer with a fully functional power converter based on the buck topology to evaluate the LV14360 series operation and performance.

Features

  • 7V to 60V input
  • Accurate 5V output
  • Up to 3A output current
  • Frequency synchronization to an external clock
  • 500kHz Switching frequency
  • Power good flag output
  • Internal compensation

Board Layout

Texas Instruments LV14360PEVM Evaluation Module
