Texas Instruments ADC354x Low-Noise Ultra-Low Power Analog-to-Digital Converters (ADCs) are low-noise, ultra-low power, 14-bit, 10 to 65MSPS, high-speed ADCs. These devices are designed for low power consumption and deliver a –155dBFS/Hz noise spectral density. The ADC354x offers great DC precision and IF sampling support, making these devices an excellent choice for a wide range of applications. High-speed control loops benefit from the short latency of only one clock cycle. The ADC consumes only 79mW at 65MSPS, and the power consumption scales very well with lower sampling rates.
The Texas Instruments ADC354x uses an SDR, DDR, or a serial CMOS interface to output the data offering the lowest power digital interface and the flexibility to minimize the number of digital interconnects. These devices are pin-to-pin compatible family with different speed grades. These devices support the extended industrial temperature range of –40°C to +105°C.
