Teltonika RUT956 Industrial Cellular Routers

Teltonika RUT956 Industrial Cellular Routers combines cellular, Wi-Fi™, and wired connectivity options with automatic WAN failover and GNSS capabilities. These routers feature SPI Flash, up to 100 simultaneous connections, a -40°C to 75°C operating temperature range, and a 10% to 90% non-condensing operating humidity range. The RUT956 routers include four four-pin industrial DC power sockets and achieve <7W maximum power consumption. These routers come with DIN rail and flat surface placement mounting options and are IP30 ingress protection rated. The RUT956 routers are used in industrial and automation, retail, transportation, and enterprise applications.

Features

Mobile:
- 4G – Cat 4 up to 150Mbps, 3G – Up to 42Mbps, and 2G – up to 236.8kbps
- Auto APN
- Band lock and used band status display
Wireless:
- IEEE 802.11b/g/n, Access Point (AP), and Station (STA)
- Up to 100 simultaneous connections
- Captive portal (hotspot) and internal/external radius server
Network:
- Static routing and dynamic routing (BGP, OSPF v2, and RIP v1/v2)
- H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets
- Ping reboot, Wget reboot, periodic reboot, LCP, and ICMP for link inspection
System:
- Mediatek, MT7628, and 580MHz CPU
- 128MB and DDR2 RAM
- 16MB and SPI Flash storage

Power:
- 4-pin industrial DC power socket
Input voltage range:
- 9V_DC to 30V_DC reverse polarity protection
- Surge protection >31V_DC 10μs maximum
Power consumption:
- <2W idle
- <7W maximum
Operating conditions:
- -40°C to 75°C operating temperature range
- 10% to 90% non-condensing operating humidity range
- IP30 ingress protection rating

Applications

Industrial and automation
Retail
Transportation

Enterprise
Energy and utilities
Smart city

Industrial Automation Applications

Teltonika RUT956 Industrial Cellular Routers

Retail Applications

Transportation Applications

Kit Contents

Router RUT956
9W PSU
2 x LTE antennas (magnetic mount, SMA male, and 3m cable)
2 x Wi-Fi antennas (magnetic mount, RP-SMA male, and 1.5m cable)
GNSS antenna (adhesive, SMA male, and 3m cable)
RS485 connector block

I/O connector block
Ethernet cable (1.5m)
SIM adapter kit
RMS flyer
Quick start guide
