TE Connectivity USB4® Gen 3 Receptacle Connectors

TE Connectivity’s (TE) USB4® Gen 3 Receptacle Connectors are backward-compatible with Thunderbolt™ 3, USB 3.x, and USB 2.0 connectors and feature excellent structure strength for a more robust connector shell. USB4 receptacle connectors transfer data up to 40Gbps and are manufactured with an advanced insert molding process that helps avoid pin-warping issues. The series offers a 20V voltage rating, 5A current rating, and -40°C to +80°C operating temperature range. TE USB 4.0 Gen 3 Receptacle Connectors offer premium performance that is required by next-generation applications such as mobile phones and notebooks in AI and IoT.

Features

Excellent signal integrity (SI) performance
Robust connector shell
Backward-compatible with Thunderbolt 3, USB 3.x, and USB 2.0 connectors

Manufactured with an advanced insert molding process
Supports resistance to damage and connection integrity during the assembly process

Applications

Tablets
Peripherals
- Monitors
- Displays
- Projectors
- Printers

Mobile phones
Notebooks
Gaming or home entertainment
- TVs
- VR/AR devices
Computing, PC, or SOC design

Specifications

24-pin mid-PCB-mount USB-C
Data transmission rate up to 40Gb/s
20V voltage rating
5A current rating
4N to 20N unmating force after 10,000 mating cycles
-40°C to +80°C operating temperature range

Materials
- LCP housing
- Stainless steel shell
- Copper alloy contact
- Stainless steel mid-plate
