TE Connectivity MATE-AX Miniaturized Automotive Coaxial Connectors

TE Connectivity’s (TE) MATE-AX Miniaturized Automotive Coaxial Connectors provide a solution for high-frequency data transmission. This highly robust, EMI-resistant, coaxial connector system for analog signal and digital data transport delivers superior data performance of up to 9GHz to 15GHz (optimized designs) maximum. Higher packaging density allows a 75% space reduction and 34% weight savings compared to standard FAKRA connectors. TE MATE-AX Connectors are designed to enable modern electrical architectures with high pin-count suitability and a diverse range of headers. MATE-AX supports existing cables which enables easy integration into existing architectures.

Features

Automotive-grade robustness, terminals and housings are designed to pass/exceed USCAR and OEM requirements
Higher bandwidth, applicable for 9GHz and up to 15GHz with optimized designs

Flexible integration based on existing wires
Cost-effective design, aligned for coaxial needs
Flexible portfolio with a range of connector sizes

Applications

Infotainment clusters
- FM
- WiFi hotspot
- Bluetooth
ADS
- 4k ADCAM
- Night vision
- Mirror replacement
- Surround-view
- Lane assist

Wireless connectivity
- Wi-Fi® and BLUETOOTH®
- 3G/4G/5G
- GPS/GNSS
- SDARS
Telematic controls
- TCU
- 3G/4G/5G
- V2X (DSRC, C-V2X)
- Bluetooth low energy
