TE Connectivity / DEUTSCH DT-XT Sealed Connector System

TE Connectivity’s (TE) DEUTSCH DT-XT Sealed Connector System features high-performance seal technology for commercial vehicle applications in harsh conditions. TE’s DT-XT Sealed Connectors use advanced seal materials that provide high flexibility for improved tear resistance. The rear seal cover protects against water ingress and are constructed of high-consistency rubber (HCR) to protect the seal from damage during terminal insertion or extraction. Housings in various color codes prevent mismating and simplify assembly.

Features

Snap-in HCR seals
- Allows flexible cable exits and movements
- Protects against damage during insertion or removal of the terminal

Housings available in various color codes
- Prevents mismating of connectors
- Simplifies assembly

Applications

ABS / ESC brake units
Actuators
Hydraulic pumps
Switches

Vehicle sensors
Solenoids
Lighting

Specifications

2, 3, 4, 6, 8, 12, and 18 circuits
30mΩ contact resistance
-55°C to +125°C operating temperature range
IP67, IP68, IP69K rated, and J2030 power-wash test capable immersion

Up to 13A current
Up to 500V_DC voltage
100 cycles minimum durability

Infographic

View Full Infographic
