TDK InvenSense SmartPressure™ Barometric Pressure Sensor

TDK InvenSense SmartPressure™ Barometric Pressure Sensor is a high-accuracy, low power, barometric pressure, and temperature sensor solution. This ICP-20100 module integrates a capacitive pressure sensor for monitoring pressure changes in the range of 30kPa to 110kPa. The sensor also has a DSP module for on-chip calibration with an analog-to-digital converter (ADC), digital filtering, a FIFO, and has I²C, I3C^SM, and SPI interfaces available. The ICP-20100 can be configured to achieve ultra-low noise or ultra-low power performance and is flexible to perform anywhere in-between. TDK InvenSense SmartPressure Barometric Pressure Sensor is available in a closed 2mm x 2mm x 0.8mm 10-pin LGA package with a vent hole. Applications include smartphones and tablets, wearable Sensors, drones and toys, fitness trackers, home and building automation, and weather stations.
