Taoglas Raptor III 7-in-1 Shark Fin Combination Antenna provides multiple antenna connections in a sleek, covert enclosure and is suitable for all automotive and commercial trucking applications. The Raptor III is engineered to be mounted directly on the vehicle roof and is supplied with 3m cables and SMA connectors as standard. The high-performance antenna is designed to combine active multiband GNSS (GPS/GLONASS/BeiDou/Galileo), 2x 5G/4G cellular MIMO, 2x dual-band Wi-Fi, active AM/FM, and TETRA antennas in a small, robust, IP67 rated enclosure. The whip antenna attached to the rear of the enclosure covers the TETRA bands used for specialist communication systems such as public safety and first responders.
The cellular antennas in the Raptor III cover all 4G and sub 6GHz 5G cellular bands offering efficiencies of up to 80%. Fallback to 3G and 2G bands are possible where 5G and 4G is not accessible. The high performing Wi-Fi antennas cover both the 2.4GHz and 5.8GHz Wi-Fi bands. The whip antenna covers the Terrestrial Trunked Radio (TETRA) bands between 380MHz and 470MHz as standard and can be customized for other communication frequency bands. It is connected via a threaded M6 Female connector to the M6 male connector on the enclosure. Low loss 1.5DS cables are used that can allow for longer cable installations if required.
The Raptor III has a robust, impact-resistant, UV resistant, PC enclosure and is easy to install. It requires just one single M20 hole. This single-hole mounting substantially reduces installation time, cost, and reduces damage to the vehicle.
