STMicroelectronics M95P32 Ultra Low-Power 32Mbit SPI Page EEPROM is optimized for mobile and wearable designs. The M95P32 32Mbit SPI Page EEPROM features a rich feature set, ultra-low power consumption, and high memory density. This device combines the patented e-STM 40nm non-volatile memory (NVM) cell technology with smart page architecture, bringing together the benefits of high memory density for firmware with byte flexibility and high endurance for simplified data logging. The M95P3 also features fast read, erase, and program cycles, reducing manufacturing costs and application downtimes by enabling rapid upload and download. Fast power-up and quad-output read to allow for faster application wake-up.
The M95P32 EEPROM offers byte and page write instructions of up to 512bytes. Write instructions consist of self-timed auto-erase and program operations, resulting in flexible data byte management. The device also accepts page/block/sector/chip erase commands to set the memory to an erased state. The memory can then be fast-programmed by pages of 512bytes and further optimized using “page program with buffer load” to hide the SPI communication latency.
An all-in-one memory designed for ultra-low power, efficient data logging, and fast firmware upload/download, The STMicroelectronics M95P32 32Mbit SPI Page EEPROM simplifies NVM integration, reduces BOM cost, and boosts power efficiency.
