STMicroelectronics LSM6DSV16BX iNEMO 3-Axis Accelerometer & Gyroscope

STMicroelectronics LSM6DSV16BX iNEMO 3-Axis Accelerometer and Gyroscope is a 3-axis digital accelerometer and a 3-axis digital gyroscope. The LSM6DSV16BX has a triple core for processing acceleration, angular rate, and Qvar sensing data on three separate channels. It has dedicated configuration, processing, and filtering. The LSM6DSV16BX integrates a UI sensor, audio accelerometer, and Qvar sensor in a compact package (2.5mm x 3.0mm x 0.71mm).

Features

Triple core for UI, bone conduction, and Qvar sensing
Power consumption 0.95mA in combo high-performance mode
“Always-on” experience with low power consumption for both accelerometer and gyroscope
Smart FIFO up to 4.5KB
±2/±4/±8/±16g full scale
±125/±250/±500/±1000/±2000/±4000 dps full scale
Analog supply voltage 1.71V to 3.6V
Independent IO supply (extended range: 1.08V to 3.6V)
Compact footprint 2.5mm x 3mm x 0.71mm
SPI / I²C and MIPI I3C v1.1 serial interface with main processor data synchronization
TDM slave interface
Advanced pedometer, step detector, and step counter

Significant motion detection, tilt detection
Standard interrupts: free-fall, wakeup, 6D orientation, click and double-click
A programmable finite state machine for accelerometer, gyroscope, and Qvar sensor data processing with a high rate @ 960Hz
Machine learning core with exportable features and filters for AI applications
Embedded Qvar electric charge variation detection
Embedded analog hub for ADC and processing analog input data
Embedded sensor fusion low-power algorithm
Embedded temperature sensor
ECOPACK and RoHS compliant

Applications

Motion tracking and gesture detection
Wearables
TWS (true wireless stereo)

IoT and connected devices
Handheld devices
Vibration detection for bone conduction
