STMicroelectronics LSM6DSV16B iNEMO Inertial Module

STMicroelectronics LSM6DSV16B iNEMO Inertial Module features a 3-axis digital accelerometer and a 3-axis digital gyroscope. The STMicroelectronics LSM6DSV16B is designed to deliver precise acceleration and angular rate sensing data processing. With dual channels dedicated to motion tracking, device power management, 3D head tracking for gaming, and an enhanced audio experience, the LSM6DSV16B offers unmatched versatility and functionality. The device also features separate channels for vibration detection for bone conduction with dedicated configuration, processing, and filtering.

Features

Dual channels for motion tracking and bone conduction
0.95mA in combo high-performance mode
“Always-on” experience with low power consumption for both accelerometer and gyroscope
Smart FIFO up to 4.5KB
±2/±4/±8/±16g full scale
±125/±250/±500/±1000/±2000/±4000dps full scale
3-axis audio accelerometer with flat and wide bandwidth > 1kHz and low noise 20μg/√Hz
SPI/I²C and MIPI I3C v1.1 serial interface with main processor data synchronization
TDM slave interface
Advanced pedometer, step detector, and step counter

Significant motion detection, tilt detection
Standard interrupts: free-fall, wakeup, 6D orientation, click and double-click
Programmable finite state machine for accelerometer, gyroscope, and external sensor data processing with a high rate @ 960Hz
Embedded adaptive self-configuration (ASC)
Embedded sensor fusion low-power algorithm
Embedded temperature sensor
1.71V to 3.6V analog supply voltage
Independent IO supply (extended range 1.08V to 3.6V)
2.5mm x 3mm x 0.71mm compact footprint
ECOPACK and RoHS compliant

Applications

True wireless stereo (TWS)
Wearables
IoT and connected devices

User interface and power management for wearable and hearable devices
