Seeed Studio EdgeLogix-RPI-1000-CM41xx032 Edge Controller

Seeed Studio EdgeLogix-RPI-1000-CM41xx032 Edge Controller offers intensive IO ports mounted, modular design, and extensive industrial bus protocols. The Seeed Studio controller has support for high-speed local buses and wireless capabilities equipped with cloud services support. The devices have increased the ability to manage complex systems and sophisticated machines.

Features

High-performance all-in-one device
- A high-performance PLC/PAC, IPC, lightweight HMI, IIoT gateway, OPC UA Server, and Industry PC all in one device
Powerful processors and flexible OS
- Powered by Raspberry Pi Compute Module 4, up to 4GB RAM and 32GB eMMC, support Debian, Linux, and Ubuntu OS
Rich IO resources and robust scalability
- Up to 24 isolated DI, DO along with RS485, RS232, CAN-FD, and 3 Gigabit Ethernet ports
- High-speed local BUS extension, supporting additional DIO, ADC, and Relay expansion modules

Multiple wireless capabilities and IT connectivity
- Build-in 2.4G/5G Wi-Fi®, BLE, mini-PCIe slot for 4G LTE and LoRaWAN modules
- Built-in IT connectivity DHCP/DNS, OPC UA, and Web service
Industrial software and cloud services support
- Support IEC 61131-3 with CODESYS, Node-RED, and MQTT
- Support AWS and Azure cloud services

Applications

Software-defined PLC
IoT gateway
SCADA

Power system
Industrial controller
Automation and control systems
