Sanyo Denki San Ace 120 9RA Low Noise, Energy Saving DC Fans

Sanyo Denki San Ace 120 9RA Low Noise, Energy Saving DC Fans are 120mm² x 25mm or 120mm² x 38mm low-noise fans that feature half the noise of previous models and 39% lower power consumption. The Sanyo Denki San Ace 120 9RA Low Noise DC Fans offer long life and a 12V to 48V rated voltage range. The series is ideal for cooling medical equipment, AV equipment, and other applications that require particularly quiet operation.

Features

Low noise (half of the current model)
Energy-saving (reduced power consumption by 28% to 39%)
12V_DC, 24V_DC, or 48V_DC rated voltages
50Hz/60Hz, 500V_AC dielectric strength for 1-minute

10MΩ minimum insulation resistance at 500V_DC (between lead wire conductors and frame)
120mm² x 25mm or 120mm² x 38mm in dimensions
-20°C to 70°C operating temperature range

Applications

Medical equipment
Built-in power supplies
AV equipment

Measuring instruments
Arcade machines
Communication equipment

Sanyo Denki San Ace 120 9RA Low Noise, Energy Saving DC Fans

Features

Applications

Application Examples
