ROHM Semiconductor BM2P10x PWM Type DC/DC Converters

ROHM Semiconductor BM2P10x PWM Type DC/DC Converters provide an optimum system for all products that include an electrical outlet. These converters include a built-in starter circuit that tolerates 650V / 800V and contributes to low power consumption. The BM2P10x converters include a current detection resistor as an internal device that can be designed as a small power supply. These PWM converters offer frequency hopping function, soft start function, under-voltage protection, and over-voltage protection. The BM2P10x converters operate at -40°C to 105°C temperature range and 8V to 10.81V power supply voltage range. Typical applications include LED lights, air conditioners, and cleaners.
