Renesas Electronics RAA227063 3-Phase Smart Gate Drivers

Renesas Electronics RAA227063 3-Phase Smart Gate Drivers integrate a self-aligned dead time generator and slew rate control to improve power efficiency. The RAA227063 has three half-bridge smart gate drivers that drive up to three N-channel MOSFET bridges. The device supports bridge voltages from 4.5V to 60V. Each gate driver supports up to 1A source and 2A sink peak drive current with programmable drive strength control.

Features

Wide V_IN range 4.5V to 60V (65V abs max)
- Switching frequency range up to 200kHz
- 3-Phase drive for BLDC application
Peak 1A/2A source/sink current with programmable drive strength
Supports 8 adjustable levels of drive strength through hardware interface and 16 adjustable levels of drive strength through SPI interface
- Adaptive and adjustable dead time
- Fully integrated power supply architecture
Two VCC LDOs allow for Sleep mode low IQ
500mA buck-boost switching regulator generates drive voltage (5V to 15V adjustable)
200mA adjustable output LDO for MCU supplies
- Flexible configuration
3-phase HI/LI mode and 3-phase PWM mode

Support half-bridge, full-bridge configuration
- Three current sense amplifiers
Four levels of sense gain setting
Supports DC offset calibration during power-up and on-the-fly
Supports both ground-side shunt sense or low-side MOSFET R_DS(ON) sense
- Back-EMF sensing for BLDC sensorless operation
- Features both hardware interface and SPI interface
- Extensive fault protection functions (VCC UV, VM/VBRIDGE UV, charge pump UV, MOSFET VDS OCP, current sense OCP, thermal warning/shutdown, buck-boost current limiting, buck-boost OCP, buck-boost UV/OV)
- Supports reverse battery protection by additional external circuitry
- 7mm x 7mm 48 Ld QFN package (0.5mm pitch)

Applications

Motor Control
Servo motor drives
Robotics
Power Tools
Gardening tools

Robotic
Tabletop
Gaming
Medical
Pumps
