Renesas / Dialog SLG47105V-EVB Evaluation Board is a demonstration and development platform for the SLG47105 GreenPAK Programmable Mixed-Signal Matrix. The SLG47105 provides a more cost-effective, one-time NVM programmable option for designers looking to integrate both digital and analog system functions while minimizing component count, board space, and power consumption for consumer and industrial motor drive applications. The device is capable of driving two brushed DC motors, a single stepper motor, solenoid, or any other load requiring up to 1.5A RMS current per output, and an operating voltage up to 13.2V.
The Renesas / Dialog SLG47105V-EVB Evaluation Board is designed to demonstrate the functionality of the SLG47105, particularly the H-Bridge, Half-Bridge, and power functions. This Evaluation Board can also be connected to the Renesas / Dialog SLG4DVKADV GreenPAK Advanced Development Board for application emulation and programming of the onboard SLG47105 device.
