Ohmite TGHE 100W Heat Sinkable Resistors

Ohmite TGHE 100W Heat Sinkable Resistors are suitable for lower power applications. These thick-film resistors offer 100W of power dissipation and come in a molded package. The thermally efficient design utilizes a ceramic base plate for better dissipation. The TGHE series delivers great thermal efficiency with 0.45K/W and a higher derating temperature of +85°C as well as stability with TCR values down to 150ppm/°C. These resistors have a non-inductive design and large resistance range from 0.24Ω to 1MΩ with a standard tolerance of 5%. Ohmite TGHE 100W Heat Sinkable Resistors feature easy connections with 0.25″ quick terminations and mount to Ohmite VX 35mm heat sink to provide a thermal solution. The TGHE series is suitable for variable speed drives, power supplies, control equipment, communication, automatic control, engine control, and other applications.
