Molex Easy-On FFC/FPC One-Touch Connectors

Molex Easy-On FFC/FPC One-Touch Connectors feature single-step mating with an auto lock-nail mechanism and high retention force for reliable connection and easy operation. These connectors offer a visible release button for easy FFC/FPC cable release operation and a lock-nail system that ensures FFC/FPC cable connection by high-retention force. The easy-on FFC/FPC connectors have an insulation resistance of 50MΩ, a dielectric withstanding voltage of 125V_AC, and operates at a temperature of up to 125°C. These connectors are ideal for use in connected mobility, car IoT infotainment, assembly automation, PCB servers, smart appliances, and LED (OLED) displays.

Features

Single-step mating with an auto lock-nail mechanism
High-retention force
Lock-nail system

Visible release button
Selective gold plating on signal terminal
Operates at a temperature of up to 125°C

Applications

Connected home/home appliances:
- Smart appliances
- Smart connected appliances
- Vending machines
Automotive:
- Connected mobility
- Comfort and infotainment
Data/computing:
- Servers/networking/storage

Consumer:
- Home entertainment
- Flat LCD/LED display panels
- Home security
Industrial:
- Connectivity
- Signal
Industrial automation:
- Automotive assembly line

Specifications

50V maximum voltage
0.5A maximum current
40mΩ maximum contact resistance

125V_AC dielectric withstanding voltage
50MΩ minimum insulation resistance
20 cycles minimum durability

Applications Overview

Molex Easy-On FFC/FPC One-Touch Connectors
