Mini-Circuits SBTX2-113-2W+ RF Transformer

Mini-Circuits SBTX2-113-2W+ RF Transformer is a surface-mount, transmission line transformer (core and semi-rigid cable) with a 2.6GHz to 11.0GHz frequency range. The 50Ω SBTX2-113-2W+ RF Transformer provides a low insertion loss (1.4dB typical) with excellent phase and amplitude performance.

The RoHS compliant SBTX2-113-2W+ is supplied in a compact 0.32″ x 0.32″ x 0.69″ AH2765 case, ideal for tight PCB layouts.

Features

2W RF power, 50Ω, 1:2 ratio
Wide 2.6GHz to 11.0GHz frequency range
Low 1.4dB (typical) insertion loss
±0.9dB (typical) amplitude unbalance
±6° (typical) low phase unbalance

22dB (typical) common mode rejection
Aqueous washable
-40°C to +85°C operating temperature range
0.32″ x 0.32″ x 0.69″ AH2765 case
RoHS compliant

Applications

Defense communication
Defense radar
Line of sight links
PCS

Cellular
Wideband push-pull amplifiers
ADC (Analog to Digital Converter)
Balanced Receivers

Technical Resources

Typical Performance Data

Performance Graphs

Outline Dimensions

Mechanical Drawing - Mini-Circuits SBTX2-113-2W+ RF Transformer
