Mikroe SPI Isolator 3 Click

Mikroe SPI Isolator 3 Click contains a digital isolator optimized for a serial peripheral interface. The board features the Maxim Integrated MAX14483 6-channel 3.75kVRMS digital galvanic isolator with a very low propagation delay on the SDI, SDO, and SCLK channels. A second enable control input allows the MAX14483 to isolate multiple SPI devices. An auxiliary channel is available for passing timing or control signals from the master side to the slave side. The MAX14483 also possesses power monitors provided for power domains to signal if the opposite side of the isolator is ready for operation.

Features

On-board modules
- Maxim Integrated MAX14483 6-channel 3.75kVRMS digital isolator with a very low propagation delay on the SDI, SDO, and SCLK channels
Low power consumption
6 isolated channels
Low propagation delay on SCLK, SDI, and SDO lines
Robust galvanic isolation of digital signals

Shared interrupt feature
Auxiliary channel for timing or control
SPI interface
mikroBUS compatibility
M (42.9mm x 25.4mm) click board size
3.3V or 5V, external input voltage

Applications

General SPI-bus isolation
Industrial, process, and building automation in programmable logic controllers, and more
