Mikroe H-Bridge 6 Click

Mikroe H-Bridge 6 Click has a DC motor driver for automotive applications and features the STMicroelectronics VNHD7008AY H-bridge motor driver. The VNHD7008AY features an under-voltage shutdown, load current limitation, overload active power limitation, overtemperature shutdown, and more. The board also contains the PCA9538A, a low-voltage 8-bit GPIO expander for communication between MCU and motor driver.

Features

On-board modules
- STMicroelectronics VNHD7008AY DC motor driver for automotive applications that integrates a full protected dual high-side driver and protection for the external power MOSFETs
Fully protected HSD with MultiSense feedback
Undervoltage shutdown
Overvoltage clamp
Load current limitation

Overload active power limitation
Overtemperature shutdown
Crosscurrent protection
Interface
- I²C, PWM
Compatibility
- mikroBUS
Click board size
- L (57.15mm x 25.4mm)

Applications

Automotive motor control applications
Automotive brushed DC motor

Body control module (BCM)
Car-seat control
