Mikroe 8800 Retro Click

Mikroe 8800 Retro Click features the ams AS1115 compact LED driver for 8×8 display screen programmed via a compatible 2-wire I²C interface. The AS1115 includes an integrated BCD code-B/HEX decoder, multiplex scan circuitry, segment and display drivers, and 64-bit memory. Internal memory stores the shift register settings, eliminating the need for continuous device reprogramming. All outputs of the AS1115 can be configured for key-readback, where key-switch status is obtained by polling for up to 64 keys, while 16 keys can be used to trigger an interrupt.

Features

On-board modules
- ams AS1115 compact LED driver for 8×8 display screen programmed via a compatible 2-wire I²C interface
Low power consumption
Individual LED segment control
Readback for 16 buttons
Interrupt feature
LED error detection

Low power shutdown current
Software reset
I²C interface
mikroBUS compatibility
L (57.15mm x 25.4mm) click board size
3.3V input voltage

Applications

Seven-segment or dot matrix user interface displays
White goods or personal electronics
