Micro Commercial Components (MCC) MCACD60N06YHE3 Dual N-Channel MOSFET

Micro Commercial Components (MCC) MCACD60N06YHE3 Dual N-Channel MOSFET is an auto-grade 60V MOSFET that delivers unmatched performance and reliability for a range of demanding applications. This MOSFET ensures optimal system performance, minimal power loss, and maximum efficiency, even in harsh and high-temperature conditions with 6.5mΩ R_DS(on). The MCACD60N06YHE3 features Split Gate Trench MOSFET technology. This MOSFET comes in a 5mm x 6mm PDFN5060 package that provides high power density and optimal thermal dissipation while enabling designs where space is a constraint. The MCACD60N06YHE3 is ideally used in automotive, industrial, and consumer applications.

Features

60V dual N-channel MOSFET
Outstanding performance and reliability
Suitable for load switches, DC-DC converters, and synchronous rectifiers
Compact design for space-saving installation
6.5mΩ low R_DS(on) for minimal power loss
240A (I_DM) pulsed drain current
50W (P_D) total power dissipation

Automotive-grade AEC-Q101-qualified
Operating junction temperature of 175°C for reliable operation in challenging environments
5mm x 6mm PDFN5060 package for high power density and optimal thermal dissipation

Applications

Automotive:
- Load switches
- DC-DC converters
- Synchronous rectifiers
Consumers:
- Power supplies
- Motor controls
- Robotics
- Cordless tools

Industrial:
- Power management systems
- Motor controls
- Power supplies
- Robotics
- Automation equipment
