MEAN WELL VFD-250P-230 & VFD-350P-230 Frequency Drives

MEAN WELL VFD-250P-230 and VFD-350P-230 Frequency Drives feature a built-in PFC function, a miniaturized size of 5″ x 3″, and a 90V_AC to 264V_AC input range. These frequency drives offer a fanless design for no-noise operation, expanding the life cycle, and are controllable with an external controller. Multiple protections are provided for these drives, including overcurrent, short circuit, overvoltage, and overtemperature. MEAN WELL VFD-250P-230 and VFD-350P-230 Drives are suitable for automatic doors, air conditioners, medical devices, and three-phase motor drives, such as BLDC, induction motors, and SynRM applications.

Features

Controllable with external controller
Fanless design for no-noise and expanding life cycle
Short-circuit protection
Overcurrent protection
Suitable for 3-phase motor drives

Provided multiple sensors for control
- Current sensor – motor torque control
- DC bus voltage sensor – overvoltage/undervoltage protection
- Temperature sensor – overtemperature protection

Applications

HVAC
Fans
Pumps
Automatic doors

Air conditioners
Conveyors
Medical devices
Fitness equipment

Specifications

5″ x 3″ miniature size
90V_AC to 264V_AC input range
250W or 350W capacity ratings
Up to 93% efficiency

47Hz to 63Hz frequency range
2.5KHz to 15KHz switching frequency range
-30°C to +70°C operating temperature range
