M5Stack M5StickT ESP32 Thermal Camera Development Kit adopts the latest FLIR Lepton 3.0 long-wave infrared (LWIR) camera core with an effective resolution of 160 x 120px for a clear and stable image. The Thermal Camera Kit is a large area non-contact infrared sensor ideal for temperature measurement. The integrated Espressif ESP32 main control chip has built-in support for Wi-Fi® and BLUETOOTH® connections, and computing speeds up to 240MHz. The screen is 1.14 inches and has a resolution of 135 x 240px.
The M5Stack M5StickT ESP32 Thermal Camera Development Kit provides a wide variety of embedded hardware resources, including an on-board 6-axis Inertial Measurement Unit, a digital microphone, and a power management chip with a built-in 300mAh battery. The device offers two programmable buttons, a rotary encoder, and a 4 Pin HY2.0 interface with I2C support.
The M5StickT ESP32 Thermal Camera Development Kit is housed in 3D printed high-quality black nylon filament with an M3 screw hole and a 1/4″ screw hole underside for easy mounting.
