M5Stack Hbridge Unit Power Management Module

M5Stack Hbridge Power Management Module is a unit DC motor drive module that uses the STM32F030+RZ7899 scheme to realize the motor drive function. This module recognizes PWM control speed, backward, forward, and braking functions using the I²C communication with the M5 host. The Hbridge unit DC motor drive module offers reliable over-temperature, over-voltage, and over-current protection that ensures the safe operation of the motor. This module features Arduino and UIFlow programming platforms and power switching. The Hbridge unit DC motor drive module operates at 0°C to 40°C temperature range and 12V input voltage. This module is ideally used in robot, motor-driven, industrial automation, and innovative home applications.
