Littelfuse SMTOAK2 Surface-Mount TVS Diodes

Littelfuse SMTOAK2 Surface-Mount TVS Diodes are housed in a modified SMTO-263 package, achieving a compact mechanical design and compatibility with automated PCB assembly. The Littelfuse SMTOAK2 TVS Diodes feature a 2kA current rating and a fast response time of <1.0ps (typical). The diodes are designed to protect sensitive electronics against surge events and inductive load-switching voltage transient events.

Features

SMTO-263 package, footprint compatible with DO-218AB package
V_BR at T_J=V_BRat +25°C x [1+αT x (T_J-25)] (αT:Temperature Coefficient), typical value is 0.1%
Glass-passivated chip junction in modified TO-263 package
ESD protection of data lines in accordance with IEC 61000-4-2, 30kV (Air), 30kV (Contact)
Fast response times typically <1.0ps from 0V to V_BR minimum
Excellent clamping capability
Low incremental surge resistance
UL Recognized compound meeting flammability rating UL 94V-0

Meets MSL level 1, per J-STD-020, LF maximum peak of +260°C
Surface-mount package to optimize board space
High-temperature reflow soldering guaranteed, +260°C/10s at terminals
Matte tin lead–free plated
Halogen-free and RoHS compliant
Lead-free E3 means 2nd level interconnect is lead-free and the terminal finish material is tin (IPC/JEDEC JSTD-609A.01)

Applications

Sensitive electronics protection
- Overvoltage surge transients
- Inductive load-switching voltage transients

Specifications

2kA current rating
15W steady state power dissipation on infinite heat sink at T_L=+75°C

-55°C to +150°C operating junction and storage temperature range
1.8°C/W typical thermal resistance junction to case
