Laird Performance Materials TYA Series Power Inductors

Laird Performance Materials TYA Series Power Inductors are low profile and high current conductors that improve performance, reliability, and power efficiency. The low profile feature benefits in consumer electronics, industrial, and telecom design. These power inductors feature extremely low DCR with greater efficiency and enable large current in small size. The TYA series include magnetic shielded structure and wire-wound construction. These inductors operate at -40°C to 85°C. Typical applications include DC-DC converters, power suppliers, LCD TV’s, gaming console, servers, printers, networking, data storage, smart meters, medical instruments, set-up box, and base stations.

Features

Magnetic shielded structure
Low DCR and high efficiency

Low profile and small size
Metal alloy core with high saturation

Specifications

-40°C to 125°C operating temperature range
-10°C to 40°C storage temperature range

70% RH maximum humidity range
1MHz test frequency

Applications

DC-DC converters and power suppliers
LCD TV’s and gaming console
Tablets, notebooks, servers, and printers

Networking and data storage
Smart meters and medical instruments
GPS, set-up box, and base stations

Laird Performance Materials TYA Series Power Inductors

Features

Specifications

Applications

Mechanical Dimension
