Infineon Technologies TLD5099EP_SEPIC Evaluation Board

Infineon Technologies TLD5099EP_SEPIC Evaluation Board evaluates the TLD5099EP DC-DC controller in SEPIC topology for high power LED applications. This evaluation board in the SEPIC topology delivers up to 21W to the load with above 84% efficiency. The TLD5099EP_SEPIC evaluation board comes with auxiliary circuits to protect the DC-DC and the load during short to ground. This evaluation board features output current adjustment trimmer, power derating circuitry, embedded PWM engine, and Cold Crank Survival Circuit (CCSC) that are enabled by jumpers. Typical applications include automotive and lighting.
