Infineon Technologies AURIX™ ShieldBuddyTC375 Development Board

Infineon Technologies AURIX™ ShieldBuddyTC375 Development Board is fitted with the Infineon TC375 32-bit multicore processor. The ShieldBuddyTC375 Board is an Arduino™ UNO R3 hardware compatible platform, allowing it to support a wide variety of application shields.

The ShieldBuddyTC375 Dev Board is supplied with basic drivers for DS-ADC, SAR, GTM, GPT, CCU6, ASC, LIN, SPI, QSPI, and Ethernet. Infineon Technologies AURIX ShieldBuddyTC375 Development Board is ideal for high end, real-time embedded industrial or automotive applications.

Features

Low cost AURIX™ TC375 board for professional and hobby use
Uses Arduino™ Due/Mega2560 form factor and IO connector pin allocation
ShieldBuddy AURIX TC375 with on-board TLF35584 power supply and safety monitor
Allows instant access for new and prospective AURIX users to hundreds of shields

Supplied with basic drivers for DS-ADC, SAR, GTM, GPT, CCU6, ASC, LIN, SPI, QSPI, Ethernet
Direct USB debug interface
Development tools based on HighTec Free AURIX Toolchain and Arduino™ Processing IDE
USB or 9-12V power supply
