Honeywell CSNV700 Flux Gate Current Sensors are non-intrusive and bring an excellent mix of performance and reliability using patented technology. These sensors are electrically isolated from the monitored circuit, thus ensuring a simple and reliable structure without loss of power to the monitored circuit. The CSNV700 sensors are designed to measure the precise battery state measurement for improved user experience and use a proprietary Honeywell technology for temperature compensation. Other features include CAN bus output with configurable ID, internal diagnostic function, UL, CE, and UKCA certifications, REACH and RoHS compliance, and multi-point temperature characterization.
The CSNV700 current sensors can be tailored and customized to meet the application’s needs, like improved time to market, lower total system cost, and enhanced reliability. These sensors are calibrated and temperature compensated for improved accuracy, AEC-Q100 qualified ICs within the sensors meet high quality and reliability standards. Typical applications include current measurement in battery management, current leakage detection, and fault detection in heavy industrial equipment.
