Honeywell ABP2 Board Mount Pressure Sensors

Honeywell ABP2 Board Mount Pressure Sensors are piezoresistive silicon pressure sensors offering a digital output for reading pressure over the specified full-scale pressure span (4bar to 12bar | 400kPa to 1.2MPa | 60psi to 175psi) and temperature range (-40°C to +110°C). Honeywell ABP2 Board Mount Pressure Sensors are calibrated and temperature compensated for sensor offset, sensitivity, temperature effects, and accuracy errors (which include non-linearity, repeatability, and hysteresis) using an onboard Application Specific Integrated Circuit (ASIC). Calibrated output values for pressure and temperature are updated at approximately 200Hz. All products are designed and manufactured according to ISO 9001 standards. The liquid-media option includes an additional silicone-based gel coating to protect the electronics under port P1, which enables use with non-corrosive liquids (water and saline) and in applications where condensation can occur.
