HARTING har-modular PCB Connectors

HARTING har-modular PCB Connectors are based on traditional DIN 41 612 style connectors offering the same robustness and durability. A modular design that locks together with a fixing rail allows users to easily configure custom connectors from off-the-shelf components providing flexibility during the production stage. The har-modular connectors feature an operating temperature range of -55°C to +125°C, current ratings up to 40A, and 500 mating cycles. HARTING har-modular PCB connectors are ideal for use in the transportation, machinery, robotics, automation, energy, and medical markets. HARTING’s har-modular is now UL approved.

Features

Modularity allows the combination of signal, power, and coax in one connector
Based on traditional DIN 41 612 style connectors with the same robustness and durability

Pre-assembled modular connectors
Designed for through-hole reflow soldering
Tested to IEC 60603-2

Applications

Drivers
Controllers
Power supplies
Embedded systems

HMI
Passenger information
Medical devices

Specifications

Current rating up to 40A
CTI >600 higher voltages up to 1000V
500 mating cycles

-55°C to +125°C temperature rating
Polyamide (PA) isolation body

Videos

Awards

HARTING’s innovative har-modular^® series took gold in the category of “Machines & Components” in the annual IDEA! Awards presented by Machine Design and Hydraulics & Pneumatics. Winners were selected by engineers from all over the world who voted on the product innovations released in the last year that they felt best fulfilled the promise of greater operational effectiveness.
