Epson Timing SG3225 Crystal Oscillators

Epson Timing SG3225 Crystal Oscillators offer a 25MHz to 500MHz frequency range, 2.5V to 3.3V supply voltage, and -40°C to +105°C temperature range. These oscillators feature an output enable function, LV-PECL or LVDS output, and 50fs phase jitter. Epson Timing SG3225 Crystal Oscillators have a 10ms startup time and 25mA to 60mA maximum current consumption range.
