ECS ECS-8X 32.768KHz Tuning Fork Crystal

ECS ECS-8X 32.768KHz Tuning Fork Crystal offers tight tolerance, long-term stability, and excellent resistance. This 32.768KHz crystal features 10ppm frequency tolerance, 12.5pF load capacitance, and 1μW drive level. The device has a 3.1mm diameter and 8.2mm length with radial terminations for through-hole mounting. ECS ECS-8X 32.768KHz Tuning Fork Crystal is used as a clock source in communication equipment, measuring instruments, microprocessors, and other time management applications. The crystal’s low-power consumption makes it ideal for portable equipment.
