Eaton LD2-HV Metalized Drum Core Inductors

Eaton LD2-HV Metalized Drum Core Inductors are high-voltage devices designed to withstand up to 1000V isolation voltage. These inductors include ferrite core material which offers high power density performance and low core losses at higher frequencies. The LD2-HV inductors feature a 0.25A to 6A current range, 1μH to 2200μH inductance range, and a high saturating current rating. These inductors comply with RoHS, J-STD-020, and Moisture Sensitivity Level (MSL) 1 standards. The LD2-HV inductors operate from -25°C to 125°C temperature range and are available in an 8.1mm x 7.3mm footprint surface mount package in a 5.3mm height. These inductors are used in AC/DC direct buck converters, smart water heaters, LED lighting, consumer electronics, smart home, smart heating systems, and IoT devices.
