DFRobot Diffuse Reflection Photoelectric Switch

DFRobot Diffuse Reflection Photoelectric Switch can detect any opaque object within 0-7m. With a 6-36V power supply, the sensor has a signal indicator for real-time status feedback and a button for adjusting detection distance. It’s also waterproof and features polarity protection.

Features

6-36V power supply voltage
0-700cm detection distance
2.5ms (1second=1000ms) response time
Detection object: any opaque object
Switching value output form
Max300mA output current
IP67 waterproof rating

IP54 protection level
ABS plastic shell material
Polarity protection, short circuit protection protection function
2m power cord length
5×5 white matt paper standard detection object
69mm x 100mm x 37mm/2.72″ x 3.94″ x 1.46″ size

Dimensions

DFRobot Diffuse Reflection Photoelectric Switch
