DFRobot 5V 3A Dual USB Step Down Buck Converter Module

DFRobot 5V 3A Dual USB Step Down Buck Converter Module is a small 8~32V converter that supports all 5V main controllers. The module has two USB ports that can output 5V/3A at the same time. With up to 85% conversion, the buck module offers excellent heat dissipation and has reverse connection protection and overload protection. When the current of any output port exceeds 3.5A, the module will switch off.

Specifications

8V-32V input voltage range
5.1±5%V no-load voltage
3A maximum output current
>85% conversion efficiency

≤5mA static power consumption
-25~65℃ working environment temperature
0~95%RH working environment humidity
