Carlo Gavazzi RM1A Zero Switching SSRs

Carlo Gavazzi RM1A Zero Switching SSRs are industrial single-phase AC Solid State Relays (SSRs) with a built-in varistor. This built-in varistor secures transient protection for heavy industrial applications. These SSRs utilize Direct Copper Bonding (DCB) technology and feature self-lifting terminals, a clip-on IP20 protection cover, and an LED indicator. The RM1A SSRs can be used for resistive, inductive, and capacitive loads. These zero-switching relays switch ON when the sinusoidal curve crosses zero and OFF when the current crosses zero. The RM1A SSRs offer up to 1400V_P blocking voltage, >4000V_ACrms opto-isolation, and two input ranges, including 3V_DC to 32V_DC and 20V_AC to 280V_AC/22V_DC to 48V_DC.
