Broadcom AFBR-S4N33C0133mm NUV-HD Single SiPM (Silicon Photomultiplier) features an active area of 3.0mm x 3.0mm in a chip-sized package. The silicon photomultiplier is used for ultra-sensitive precision measurement of single photons. The Broadcom AFBR-S4N33C013 allows high packing density of the single chips using through-silicon-via (TSV) technology and a chip-sized package (CSP). Larger areas can be covered by tiling multiple AFBR-S4N33C013 CSPs with few edge losses. The protective layer is made of highly transparent glass down to UV wavelengths. The protective layer results in a broad response in the visible light spectrum with high sensitivity towards blue- and near-UV regions of the light spectrum.
The AFBR-S4N33C013 SiPM is designed for the detection of low-level pulsed light sources. These are especially suited for the detection of Cherenkov- or scintillation light from the most common organic (plastic) and inorganic scintillator materials (for example, LSO, LYSO, BGO, NaI, CsI, BaF, LaBr).
The AFBR-S4N33C013 NUV-HD SiPM has an operating temperature range from -40°C to +85°Cand is lead-free and RoHS-compliant.
